Panduit T100P-C0

Panduit Spiral Wrap, offers abrasion protection for wires, cables, hoses and tubing, 1" (25.4mm) x 100' outside diameter, weather resistant polypropylene, black. [T100P-C0]; PAP101

by Panduit
11.304.500₫
(Giá chưa VAT).
Mã kho: PAP101

Mã nhà sản xuất: T100P-C0

Đơn vị tính: PC

Quy cách đóng gói: 1

Liên hệ để có giá tốt (Vietnam: 0898.332.898,  E-mail: SKF@nguyenxuong.com)

Wire Routing Management Protection / Abrasion Protection / Cable Sleeves Tools Wraps: Panduit T100P-C0

MÔ TẢ SẢN PHẨM

The T100P-C0 Polypropylene Spiral Wrap provides continuous abrasion protection for wires, cables, and tubing. The spiral wrap harnesses multiple cables into a single manageable bundle while allowing for breakouts. Lightweight, flexible, durable protection allows for use with irregular shapes. Instal

_THÔNG SỐ KỸ THUẬT:

Application Harness Multiple Cables Into a Single Manageable Bundle; Allows Breakouts of Single/Multiple Cables; Provides Abrasion Protection for Wire, Cables, Hoses, and Tubing
Product Type Spiral Wrap
Color Black
Environment Indoor and Outdoor
Flammability Rating UL94-HB
Includes Installation Tool
Material Weather Resistant Polypropylene
Resistance Properties Abrasion Resistance; Weather Resistant
Maximum Bundle Diameter (In.) 6
Maximum Bundle Diameter (mm) 152.4
Maximum Operating Temperature (°C) 115
Maximum Operating Temperature (°F) 239
Minimum Bundle Diameter (In.) 0.875
Minimum Bundle Diameter (mm) 22.2
Minimum Operating Temperature (°C) -40
Minimum Operating Temperature (°F) -40
Outer Diameter (In.) 1
Outer Diameter (mm) 25.4
Overall Length (ft.) 100
Overall Length (m) 30.5
Standards Met UL Recognized - E141152; UL94HB
Wall Thickness (In.) 0.03
Wall Thickness (mm) 0.76
Part Features Allows breakouts of single/multiple cables, Provides abrasion protection for wire, cables, hoses and tubing. Multiple colors allow for easy identification of cable bundles. Installation tool is supplied and the spiral wrap is reusable.
