4.5 V to 60 V Input, 3A microBUCK® DC/DC [SIC468ED-T1-GE3]; 188-5074
by Vishay
0₫
Mã kho: 1885074
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Output Current | 3A |
| Regulator Function | Synchronous Buck Regulator |
| Minimum Output Voltage | 0.8 V |
| Minimum Input Voltage | 4.5 V |
| Maximum Input Voltage | 60 V |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Pin Count | 27 |
| Package Type | PowerPAK MLP55 |
| Switching Regulator | Yes |
| Width | 5.1mm |
| Maximum Switching Frequency | 2 MHz |
| Maximum Operating Temperature | +150 °C |
| Height | 0.75mm |
| Dimensions | 5.1 x 5.1 x 0.75mm |
| Length | 5.1mm |
| Efficiency | 98 (Peak)% |
| Minimum Operating Temperature | -40 °C |
