Texas Instruments, LMZ10503TZE-ADJ/NOPB DC-DC Converter 3A Adjustable, 0.8 to 5 V 7-Pin, TO-PMOD [LMZ10503TZE-ADJ/NOPB]; 121-9326
0₫
Mã kho: 1219326
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Maximum Output Current | 3A |
Maximum Output Voltage | 5 V |
Regulator Function | Buck Controller |
Minimum Output Voltage | 0.8 V |
Minimum Input Voltage | 2.95 V |
Maximum Input Voltage | 5.5 V |
Output Type | Adjustable |
Mounting Type | Surface Mount |
Number of Outputs | 1 |
Pin Count | 7 |
Package Type | TO-PMOD |
Switching Regulator | Yes |
Line Regulation | 0.0004 |
Load Regulation | 0.0025 |
Maximum Switching Frequency | 1160 kHz |
Length | 10.16mm |
Dimensions | 10.16 x 9.85 x 4.57mm |
Width | 9.85mm |
Minimum Operating Temperature | -40 °C |
Height | 4.57mm |
Maximum Operating Temperature | +125 °C |
