Texas Instruments, LMR14020SQDDAQ1 Step-Down Switching Regulator 2A Adjustable, 0.8 → 28 V 8-Pin, SO PowerPAD [LMR14020SQDDAQ1]; 133-0677
0₫
Mã kho: 1330677
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Output Current | 2A |
| Maximum Output Voltage | 28 V |
| Regulator Function | Step Down |
| Minimum Output Voltage | 0.8 V |
| Minimum Input Voltage | 4 V |
| Maximum Input Voltage | 40 V |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Pin Count | 8 |
| Package Type | SO PowerPAD |
| Switching Regulator | Yes |
| Dimensions | 5 x 4 x 1.55mm |
| Length | 5mm |
| Maximum Switching Frequency | 2.5 MHz |
| Maximum Operating Temperature | +125 °C |
| Height | 1.55mm |
| Minimum Operating Temperature | -40 °C |
| Width | 4mm |
