Texas Instruments, LM22677TJ-ADJ/NOPB Step-Down Switching Regulator 5A Adjustable 7-Pin D2PAK [LM22677TJ-ADJ/NOPB]; 162-5054
0₫
Mã kho: 1625054
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Output Current | 5A |
| Regulator Function | Buck Controller |
| Minimum Output Voltage | 1.258 V |
| Minimum Input Voltage | 4.5 V |
| Maximum Input Voltage | 42 V |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Pin Count | 7 |
| Package Type | D2PAK (TO-263) |
| Switching Regulator | Yes |
| Minimum Operating Temperature | -40 °C |
| Width | 9.85mm |
| Height | 2mm |
| Maximum Operating Temperature | +125 °C |
| Efficiency | 0.9 |
| Length | 10.16mm |
| Dimensions | 10.16 x 9.85 x 2mm |
| Maximum Switching Frequency | 1000 kHz |
