Monolithic Power Systems (MPS), MP4420GJ-P Step-Down Switching Regulator 2A Adjustable 8-Pin, TSOT-23 [MP4420GJ-P]; 170-9383
0₫
Mã kho: 1709383
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Output Current | 2A |
| Regulator Function | Step Down |
| Minimum Output Voltage | 0.8 V |
| Minimum Input Voltage | 4 V |
| Maximum Input Voltage | 30 V |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Pin Count | 8 |
| Package Type | TSOT-23 |
| Switching Regulator | Yes |
| Load Regulation | 0.04 |
| Minimum Operating Temperature | -40 °C |
| Width | 1.7mm |
| Dimensions | 3 x 1.7 x 0.9mm |
| Maximum Operating Temperature | +125 °C |
| Length | 3mm |
| Height | 0.9mm |
| Maximum Switching Frequency | 500 kHz |
