Linear Technology, LT1172CQ#PBF DC-DC Converter 5A 5-Pin, DD [LT1172CQ#PBF]; 145-7673
0₫
Mã kho: 1457673
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Output Current | 5A |
| Maximum Output Voltage | 65 V |
| Regulator Function | Standard |
| Minimum Input Voltage | 3 V |
| Maximum Input Voltage | 60 V |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Pin Count | 5 |
| Package Type | DD |
| Switching Regulator | Yes |
| Line Regulation | 0.03 %/V |
| Maximum Operating Temperature | +100 °C |
| Length | 10.54mm |
| Width | 10.922mm |
| Minimum Operating Temperature | 0 °C |
| Maximum Switching Frequency | 115 kHz |
| Dimensions | 10.541 x 10.922 x 4.572mm |
| Height | 4.572mm |
