ANA ADJV .5A PWR SW REG [LM2576TV-ADJG]; 184-4234
0₫
Mã kho: 1844234
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Regulator Function | Step Down |
| Maximum Output Current | 3A |
| Number of Outputs | 1 |
| Mounting Type | Through Hole |
| Package Type | TO-220 |
| Pin Count | 5 |
| Output Type | Adjustable |
| Maximum Switching Frequency | 63 kHz |
| Switching Regulator | Yes |
| Efficiency | 0.77 |
| Dimensions | 10.54 x 4.57 x 15.57mm |
| Height | 15.57mm |
| Maximum Output Voltage | 37 V |
| Minimum Input Voltage | 7 V |
| Length | 10.54mm |
| Maximum Operating Temperature | +125 °C |
| Minimum Output Voltage | 1.23 V |
| Minimum Operating Temperature | -40 °C |
| Width | 4.57mm |
| Maximum Input Voltage | 40 V |
