Vishay VS-1KAB80E, Bridge Rectifier, 1.2A 800V, 4-Pin D 38 [VS-1KAB80E]; 296-5397
by Vishay
0₫
Mã kho: 2965397
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Peak Average Forward Current | 1.2A |
| Bridge Type | Single Phase |
| Peak Reverse Repetitive Voltage | 800V |
| Mounting Type | Through Hole |
| Package Type | D 38 |
| Pin Count | 4 |
| Configuration | Single |
| Peak Non-Repetitive Forward Surge Current | 52A |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | -40 °C |
| Peak Forward Voltage | 1.1V |
| Peak Reverse Current | 10µA |
| Length | 9.5mm |
| Dimensions | 9.5 x 9.5 x 10mm |
| Height | 10mm |
| Width | 9.5mm |
