![Vishay KBU4G-E4/51 6296667](http://nguyenxuong.com/cdn/shop/products/R630803-01_b61d77df-2a86-437a-8d29-5c83e9b0ec18_178x351.jpg?v=1594045605)
Vishay KBU4G-E4/51, Bridge Rectifier, 4A 400V, 4-Pin KBU [KBU4G-E4/51]; 629-6667
by Vishay
0₫
Mã kho: 6296667
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Peak Average Forward Current | 4A |
Bridge Type | Single Phase |
Peak Reverse Repetitive Voltage | 400V |
Mounting Type | Through Hole |
Package Type | KBU |
Pin Count | 4 |
Configuration | Single |
Peak Non-Repetitive Forward Surge Current | 200A |
Maximum Operating Temperature | +150 °C |
Minimum Operating Temperature | -50 °C |
Peak Forward Voltage | 1V |
Peak Reverse Current | 5µA |
Length | 23.7mm |
Dimensions | 23.7 x 7.1 x 19.3mm |
Width | 7.1mm |
Height | 19.3mm |
