ON Semiconductor GBPC2504W, Bridge Rectifier, 25A 400V, 4-Pin GBPC-W [GBPC2504W]; 803-1901
0₫
Mã kho: 8031901
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Bridge Type | Single Phase |
Peak Average Forward Current | 25A |
Peak Reverse Repetitive Voltage | 400V |
Mounting Type | Through Hole |
Package Type | GBPC-W |
Pin Count | 4 |
Diode Technology | Silicon Junction |
Configuration | Single |
Peak Non-Repetitive Forward Surge Current | 300A |
Maximum Operating Temperature | +150 °C |
Minimum Operating Temperature | -55 °C |
Peak Forward Voltage | 1.1V |
Peak Reverse Current | 500µA |
Length | 29mm |
Width | 29mm |
Height | 11.23mm |
Dimensions | 29 x 29 x 11.23mm |
