ON Semiconductor DF005S, Bridge Rectifier, 1.5A 50V, 4-Pin SDIP [DF005S]; 369-0303
0₫
Mã kho: 3690303
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Bridge Type | Single Phase |
Peak Average Forward Current | 1.5A |
Peak Reverse Repetitive Voltage | 50V |
Mounting Type | Surface Mount |
Package Type | SDIP |
Pin Count | 4 |
Configuration | Single |
Peak Non-Repetitive Forward Surge Current | 50A |
Maximum Operating Temperature | +150 °C |
Minimum Operating Temperature | -55 °C |
Peak Forward Voltage | 1.1V |
Peak Reverse Current | 5µA |
Length | 8.51mm |
Width | 6.5mm |
Height | 3.3mm |
Dimensions | 8.51 x 6.5 x 3.3mm |
