HY Electronic Corp SBR3512, 3-phase Bridge Rectifier, 35A 1200V, 5-Pin SBR [SBR3512]; 917-9035
0₫
Mã kho: 9179035
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Bridge Type | Three Phase |
| Peak Average Forward Current | 35A |
| Peak Reverse Repetitive Voltage | 1200V |
| Mounting Type | Through Hole |
| Package Type | SBR |
| Pin Count | 5 |
| Diode Type | Silicon Junction |
| Diode Technology | Silicon Junction |
| Configuration | Single |
| Peak Non-Repetitive Forward Surge Current | 500A |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | -55 °C |
| Peak Forward Voltage | 1.2V |
| Peak Reverse Current | 5mA |
| Length | 28.8mm |
| Height | 11.5mm |
| Dimensions | 28.8 x 28.8 x 11.5mm |
| Width | 28.8mm |
