Diodes Inc DF08S-T, Bridge Rectifier, 1A 800V, 4-Pin DF-S [DF08S-T]; 823-4052
by DiodesZetex
0₫
Mã kho: 8234052
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Bridge Type | Single Phase |
| Peak Average Forward Current | 1A |
| Peak Reverse Repetitive Voltage | 800V |
| Mounting Type | Surface Mount |
| Package Type | DF-S |
| Pin Count | 4 |
| Configuration | Single |
| Peak Non-Repetitive Forward Surge Current | 100A |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | -65 °C |
| Peak Forward Voltage | 1.1V |
| Peak Reverse Current | 500µA |
| Length | 8.51mm |
| Width | 6.5mm |
| Dimensions | 8.51 x 6.5 x 2.6mm |
| Height | 2.6mm |
