| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Regulator Function | Boost, Buck, Flyback, Forward, Inverting |
| Maximum Output Current | 5A |
| Number of Outputs | 1 |
| Line Regulation | 0.03 %/V |
| Mounting Type | Surface Mount |
| Package Type | DD |
| Pin Count | 5 |
| Maximum Switching Frequency | 115 kHz |
| Switching Regulator | Yes |
| Dimensions | 10.541 x 10.922 x 4.572mm |
| Height | 4.572mm |
| Width | 10.922mm |
| Minimum Operating Temperature | 0 °C |
| Length | 10.54mm |
| Maximum Input Voltage | 60 V |
| Minimum Input Voltage | 3 V |
| Maximum Operating Temperature | +100 °C |
| Maximum Output Voltage | 75 V |
