| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Transistor Type | PNP |
| Maximum DC Collector Current | 150 mA |
| Maximum Collector Emitter Voltage | 50 V |
| Package Type | TO-92 |
| Mounting Type | Through Hole |
| Maximum Power Dissipation | 400 mW |
| Minimum DC Current Gain | 70 |
| Transistor Configuration | Single |
| Maximum Collector Base Voltage | -50 V |
| Maximum Emitter Base Voltage | -5 V |
| Maximum Operating Frequency | 1 MHz |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Height | 5.33mm |
| Maximum Operating Temperature | +150 °C |
| Length | 5.2mm |
| Dimensions | 5.2 x 4.19 x 5.33mm |
| Maximum Collector Emitter Saturation Voltage | -0.3 V |
| Width | 4.19mm |
| Maximum Base Emitter Saturation Voltage | -1.1 V |
