| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Transistor Type | NPN |
| Maximum DC Collector Current | 0.208333333333333 |
| Maximum Collector Emitter Voltage | 450 V |
| Package Type | TO-220F |
| Mounting Type | Through Hole |
| Maximum Power Dissipation | 40 W |
| Transistor Configuration | Single |
| Maximum Collector Base Voltage | 1000 V |
| Maximum Emitter Base Voltage | 9 V |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Maximum Base Emitter Saturation Voltage | 1.3 V |
| Maximum Operating Temperature | +150 °C |
| Maximum Collector Emitter Saturation Voltage | 1.5 V |
| Width | 4.7mm |
| Dimensions | 10.16 x 4.7 x 15.87mm |
| Length | 10.16mm |
| Height | 15.87mm |
