Wurth Elektronik 1200μF 6.3V dc Aluminium Polymer Capacitor, Through Hole 10 (Dia.) x 12.5mm +105°C 10mm 5mm [870235175007]; 163-7186
0₫
Mã kho: 1637186
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1200 µF |
| Voltage | 6.3 V dc |
| Mounting Type | Through Hole |
| Technology | Polymer |
| Dimensions | 10 (Dia.) x 12.5mm |
| Height | 12.5mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 5mm |
| Lifetime | 5000h |
| Series | WCAP-PT5H |
| Dissipation Factor | 10 |
| Equivalent Series Resistance | 7mΩ |
| Ripple Current | 6.64A |
| Leakage Current | 756 μA |
| Tolerance | ±20% |
