Wurth Elektronik 1000μF 6.3V dc Aluminium Polymer Capacitor, Through Hole 8 (Dia.) x 11.5mm +125°C 8mm 3.5mm [870135174006]; 163-7168
0₫
Mã kho: 1637168
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 1000 µF |
Voltage | 6.3 V dc |
Mounting Type | Through Hole |
Technology | Polymer |
Dimensions | 8 (Dia.) x 11.5mm |
Height | 11.5mm |
Minimum Operating Temperature | -55°C |
Diameter | 8mm |
Maximum Operating Temperature | +125°C |
Lead Pitch | 3.5mm |
Lifetime | 2000h |
Series | WCAP-PTHT |
Leakage Current | 630 μA |
Dissipation Factor | 10 |
Equivalent Series Resistance | 9mΩ |
Ripple Current | 6.1A |
Tolerance | ±20% |
