Wurth Elektronik 47μF 25V dc Aluminium Polymer Capacitor, Through Hole 8 (Dia.) x 8mm +105°C 8mm 3.5mm [870025574002]; 163-7129
0₫
Mã kho: 1637129
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 47 µF |
Voltage | 25 V dc |
Mounting Type | Through Hole |
Technology | Polymer |
Dimensions | 8 (Dia.) x 8mm |
Height | 8mm |
Minimum Operating Temperature | -55°C |
Diameter | 8mm |
Maximum Operating Temperature | +105°C |
Lifetime | 2000h |
Lead Pitch | 3.5mm |
Series | WCAP-PTG5 |
Tolerance | ±20% |
Leakage Current | 235 μA |
Dissipation Factor | 8 |
Ripple Current | 4.5A |
Equivalent Series Resistance | 20mΩ |
