Wurth Elektronik 47μF 16V dc Aluminium Electrolytic Capacitor, Surface Mount 7.7 (Dia.) x 6.15mm +85°C 7.7mm 2.2mm [865250345006]; 839-5078
0₫
Mã kho: 8395078
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 47 µF |
| Voltage | 16 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 7.7 (Dia.) x 6.15mm |
| Height | 6.15mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 7.7mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 2.2mm |
| Lifetime | 2000h |
| Series | WCAP-ASNP |
| Polarised | Polar |
| Leakage Current | 37.6 μA |
| Ripple Current | 51mA |
| Dissipation Factor | 17 |
| Tolerance | ±20% |
