Wurth Elektronik 4.7μF 50V dc Aluminium Electrolytic Capacitor, Surface Mount 5.5 (Dia.) x 4.85mm +105°C 5.5mm 1.4mm [865230642008]; 163-5851
0₫
Mã kho: 1635851
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 4.7 µF |
Voltage | 50 V dc |
Mounting Type | Surface Mount |
Technology | Electrolytic |
Dimensions | 5.5 (Dia.) x 4.85mm |
Height | 4.85mm |
Minimum Operating Temperature | -40°C |
Diameter | 5.5mm |
Maximum Operating Temperature | +105°C |
Lead Pitch | 1.4mm |
Lifetime | 5000h |
Series | WCAP-AS5H |
Polarised | Polar |
Dissipation Factor | 12 |
Tolerance | ±20% |
Ripple Current | 19mA |
Leakage Current | 3 μA |
