![Wurth Elektronik 865230153006 1635812](http://nguyenxuong.com/cdn/shop/products/R8387894-01_da1e1f7e-3cc8-47fc-92f3-8a91a453c7ec_444x359.jpg?v=1594360249)
Wurth Elektronik 330μF 6.3V dc Aluminium Electrolytic Capacitor, Surface Mount 10.5 (Dia.) x 7.85mm +105°C 10.5mm [865230153006]; 163-5812
0₫
Mã kho: 1635812
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 330 µF |
Voltage | 6.3 V dc |
Mounting Type | Surface Mount |
Technology | Electrolytic |
Dimensions | 10.5 (Dia.) x 7.85mm |
Height | 7.85mm |
Minimum Operating Temperature | -40°C |
Diameter | 10.5mm |
Maximum Operating Temperature | +105°C |
Lead Pitch | 3.1mm |
Lifetime | 5000h |
Series | WCAP-AS5H |
Dissipation Factor | 32 |
Ripple Current | 160mA |
Tolerance | ±20% |
Leakage Current | 20.79 μA |
Polarised | Polar |
