Wurth Elektronik 22μF 6.3V dc Aluminium Electrolytic Capacitor, Surface Mount 5.5 (Dia.) x 3.85mm +105°C 5.5mm 1mm [865230140001]; 163-5806
0₫
Mã kho: 1635806
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 22 µF |
| Voltage | 6.3 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 5.5 (Dia.) x 3.85mm |
| Height | 3.85mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 5.5mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 1mm |
| Lifetime | 5000h |
| Series | WCAP-AS5H |
| Dissipation Factor | 32 |
| Ripple Current | 22mA |
| Leakage Current | 3 μA |
| Tolerance | ±20% |
| Polarised | Polar |
