Wurth Elektronik 68μF 25V dc Aluminium Electrolytic Capacitor, Surface Mount 6.3 (Dia.) x 5.35mm +105°C 6.3mm 2.2mm [865080443009]; 163-5718
0₫
Mã kho: 1635718
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 68 µF |
Voltage | 25 V dc |
Mounting Type | Surface Mount |
Technology | Electrolytic |
Dimensions | 6.3 (Dia.) x 5.35mm |
Height | 5.35mm |
Minimum Operating Temperature | -55°C |
Diameter | 6.3mm |
Maximum Operating Temperature | +105°C |
Lifetime | 2000h |
Lead Pitch | 2.2mm |
Series | WCAP-ASLI |
Dissipation Factor | 14 |
Ripple Current | 240mA |
Tolerance | ±20% |
Leakage Current | 17 μA |
Polarised | Polar |
