Wurth Elektronik 33μF 25V dc Aluminium Electrolytic Capacitor, Surface Mount 5.5 (Dia.) x 6.15mm +105°C 5.5mm 2.2mm [865060443003]; 163-6371
0₫
Mã kho: 1636371
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 33 µF |
| Voltage | 25 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 5.5 (Dia.) x 6.15mm |
| Height | 6.15mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 5.5mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 2000h |
| Lead Pitch | 2.2mm |
| Series | WCAP-ASLL |
| Polarised | Polar |
| Tolerance | ±20% |
| Ripple Current | 230mA |
| Leakage Current | 8.25 μA |
| Dissipation Factor | 14 |
