Wurth Elektronik 33μF 6.3V dc Aluminium Electrolytic Capacitor, Surface Mount 5.5 (Dia.) x 3.85mm +105°C 5.5mm 1mm [865060140002]; 163-6331
0₫
Mã kho: 1636331
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 33 µF |
Voltage | 6.3 V dc |
Mounting Type | Surface Mount |
Technology | Electrolytic |
Dimensions | 5.5 (Dia.) x 3.85mm |
Height | 3.85mm |
Minimum Operating Temperature | -55°C |
Diameter | 5.5mm |
Maximum Operating Temperature | +105°C |
Lifetime | 2000h |
Lead Pitch | 1mm |
Series | WCAP-ASLL |
Polarised | Polar |
Dissipation Factor | 22 |
Ripple Current | 85mA |
Tolerance | ±20% |
Leakage Current | 3 μA |
