Wurth Elektronik 68μF 450V dc Aluminium Electrolytic Capacitor, Through Hole 22 (Dia.) x 26mm +85°C 22mm 10mm [861221483001]; 124-7473
0₫
Mã kho: 1247473
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 68 µF |
| Voltage | 450 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 22 (Dia.) x 26mm |
| Depth | 26mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 22mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 10mm |
| Lifetime | 3000h |
| Series | WCAP-AIE8 |
| Ripple Current | 710mA |
| Dissipation Factor | 0.2 |
| Tolerance | ±20% |
| Polarised | Polar |
| Leakage Current | 524.79 μA |
