Wurth Elektronik 82μF 450V dc Aluminium Electrolytic Capacitor, Through Hole 25 (Dia.) x 21mm +85°C 25mm 10mm [861101484009]; 124-7457
0₫
Mã kho: 1247457
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 82 µF |
| Voltage | 450 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 25 (Dia.) x 21mm |
| Depth | 21mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 25mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 10mm |
| Lifetime | 2000h |
| Series | WCAP-AIL8 |
| Dissipation Factor | 0.2 |
| Ripple Current | 890mA |
| Tolerance | ±20% |
| Polarised | Polar |
| Leakage Current | 738 μA |
