Wurth Elektronik 6800μF 16V dc Aluminium Electrolytic Capacitor, Through Hole 18 (Dia.) x 35.5mm +105°C 18mm 7.5mm [860160381047]; 839-4435
0₫
Mã kho: 8394435
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 6800 µF |
| Voltage | 16 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 18 (Dia.) x 35.5mm |
| Height | 35.5mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 18mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 7000h |
| Lead Pitch | 7.5mm |
| Series | WCAP-ATLL |
| Leakage Current | 1088 μA |
| Ripple Current | 3.252A |
| Tolerance | ±20% |
| Dissipation Factor | 16 |
