Wurth Elektronik 390μF 16V dc Aluminium Electrolytic Capacitor, Through Hole 8 (Dia.) x 11.5mm +105°C 8mm 3mm [860160374022]; 163-7014
0₫
Mã kho: 1637014
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 390 µF |
Voltage | 16 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 8 (Dia.) x 11.5mm |
Height | 11.5mm |
Minimum Operating Temperature | -55°C |
Diameter | 8mm |
Maximum Operating Temperature | +105°C |
Lead Pitch | 3mm |
Lifetime | 4000h |
Series | WCAP-ATLL |
Tolerance | ±20% |
Leakage Current | 62.4 μA |
Dissipation Factor | 16 |
Ripple Current | 612mA |
