Wurth Elektronik 6800μF 10V dc Aluminium Electrolytic Capacitor, Through Hole 16 (Dia.) x 31.5mm +105°C 16mm 7.5mm [860080280026]; 163-7635
0₫
Mã kho: 1637635
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 6800 µF |
Voltage | 10 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 16 (Dia.) x 31.5mm |
Height | 31.5mm |
Minimum Operating Temperature | -55°C |
Diameter | 16mm |
Maximum Operating Temperature | +105°C |
Lead Pitch | 7.5mm |
Lifetime | 5000h |
Series | WCAP-ATLI |
Leakage Current | 680 μA |
Ripple Current | 3.63A |
Dissipation Factor | 14 |
Tolerance | ±20% |
