Wurth Elektronik 4.7μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 8 (Dia.) x 11.5mm +85°C 8mm 3.5mm [860011374005]; 163-6143
0₫
Mã kho: 1636143
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 4.7 µF |
Voltage | 400 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 8 (Dia.) x 11.5mm |
Height | 11.5mm |
Minimum Operating Temperature | -40°C |
Diameter | 8mm |
Maximum Operating Temperature | +85°C |
Lifetime | 2000h |
Lead Pitch | 3.5mm |
Series | WCAP-ATG8 |
Dissipation Factor | 15 |
Ripple Current | 55mA |
Tolerance | ±20% |
Leakage Current | 56.4 μA |
