Wurth Elektronik 820μF 50V dc Aluminium Electrolytic Capacitor, Through Hole 13 (Dia.) x 25mm +85°C 13mm 5mm [860010678023]; 163-6129
0₫
Mã kho: 1636129
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 820 µF |
| Voltage | 50 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 13 (Dia.) x 25mm |
| Height | 25mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 13mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 5mm |
| Lifetime | 2000h |
| Series | WCAP-ATG8 |
| Ripple Current | 1.287A |
| Dissipation Factor | 10 |
| Leakage Current | 410 μA |
| Tolerance | ±20% |
