Wurth Elektronik 15000μF 10V dc Aluminium Electrolytic Capacitor, Through Hole 18 (Dia.) x 35.5mm +85°C 18mm 7.5mm [860010281030]; 163-6488
0₫
Mã kho: 1636488
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 15000 µF |
Voltage | 10 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 18 (Dia.) x 35.5mm |
Height | 35.5mm |
Length | 18mm |
Minimum Operating Temperature | -40°C |
Diameter | 18mm |
Maximum Operating Temperature | +85°C |
Lead Pitch | 7.5mm |
Lifetime | 2000h |
Series | WCAP-ATG8 |
Leakage Current | 1500 μA |
Dissipation Factor | 19 |
Ripple Current | 3.31A |
Tolerance | ±20% |
