Screw Terminal Capacitor 4700uF 400V 76x [MAL250136472E3]; 187-6501
by Vishay
0₫
Mã kho: 1876501
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 4700 µF |
| Voltage | 400 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 76.4 Dia. x 105.8mm |
| Height | 105.8mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 76.4mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 31.8mm |
| Lifetime | 5000h |
| Series | 501 |
| Polarised | Polar |
| Equivalent Series Resistance | 43mΩ |
| Ripple Current | 14.6A |
| Leakage Current | 3.76 mA |
| Tolerance | ±20% |
