Vishay 330μF 200V dc Aluminium Electrolytic Capacitor, Through Hole 23 Dia. x 32mm 23mm 10mm [MAL225952331E3]; 174-0544
by Vishay
0₫
Mã kho: 1740544
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 330 µF |
| Voltage | 200 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 23 Dia. x 32mm |
| Height | 32mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 23mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 10mm |
| Lifetime | 3000h |
| Series | 259 PHM-SI |
| Ripple Current | 1.68A |
| Tolerance | ±20% |
| Leakage Current | 660 μA |
| Equivalent Series Resistance | 340mΩ |
| Polarised | Polar |
