Vishay 1200μF 250V dc Aluminium Electrolytic Capacitor, Through Hole 36 Dia. x 42mm 36mm 10mm [MAL225923122E3]; 174-0507
by Vishay
0₫
Mã kho: 1740507
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1200 µF |
| Voltage | 250 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 36 Dia. x 42mm |
| Height | 42mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 36mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 3000h |
| Lead Pitch | 10mm |
| Series | 259 PHM-SI |
| Polarised | Polar |
| Equivalent Series Resistance | 120mΩ |
| Tolerance | ±20% |
| Ripple Current | 3.34A |
| Leakage Current | 3 mA |
