Vishay 33μF 63V dc Hybrid Conductive Polymer Aluminium Capacitor, Surface Mount 8.5 x 8.5 x 10.8mm 8mm 3.1mm 8.5mm [MAL218397803E3]; 174-0179
by Vishay
0₫
Mã kho: 1740179
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 33 µF |
| Voltage | 63 V dc |
| Mounting Type | Surface Mount |
| Technology | Hybrid |
| Dimensions | 8.5 x 8.5 x 10.8mm |
| Height | 10.8mm |
| Length | 8.5mm |
| Depth | 8.5mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 8mm |
| Maximum Operating Temperature | +125°C |
| Lead Pitch | 3.1mm |
| Lifetime | 256000 h @ 65 °C |
| Series | 183 CPHT |
| Tolerance | ±20% |
| Automotive Standard | AEC-Q200 |
| Polarised | Polar |
| Leakage Current | 20.8 μA |
| Dissipation Factor | 0.0008 |
| Ripple Current | 1.1A |
| Equivalent Series Resistance | 40mΩ |
