Vishay 2200μF 100V dc Aluminium Electrolytic Capacitor, Through Hole 30 (Dia.) x 40mm +85°C 30mm 10mm [MAL205659222E3]; 172-7715
by Vishay
0₫
Mã kho: 1727715
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 2200 µF |
| Voltage | 100 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 30 (Dia.) x 40mm |
| Height | 40mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 30mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 10mm |
| Lifetime | 5000h |
| Series | 56 |
| Ripple Current | 2.27A |
| Tolerance | ±20% |
| Leakage Current | 444 μA, 1324 μA |
