Vishay 150μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 25.7 x 79.8mm +105°C 25.7mm [53D151F400JS6E3]; 855-6249
by Vishay
0₫
Mã kho: 8556249
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 150 µF |
| Voltage | 400 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 25.7 x 79.8mm |
| Height | 79.8mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 25.7mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 1000h |
| Series | 53D |
| Tolerance | -10 → +50% |
| Equivalent Series Resistance | 1.011Ω |
| Ripple Current | 820mA |
