![RS PRO 1815458](http://nguyenxuong.com/cdn/shop/products/Y1815458-01_444x129.jpg?v=1594182908)
RS PRO 100μF 35V dc Aluminium Capacitors, Through Hole 6 Dia. x 11mm +105°C 6mm 2.5mm; 181-5458
by RS PRO
0₫
Mã kho: 1815458
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 100 µF |
Voltage | 35 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 6 Dia. x 11mm |
Height | 11mm |
Minimum Operating Temperature | -40°C |
Diameter | 6mm |
Maximum Operating Temperature | +105°C |
Lead Pitch | 2.5mm |
Lifetime | 1000h |
Tolerance | ±20% |
Ripple Current | 390mA |
Dissipation Factor | 0.12 |
Leakage Current | 3 μA |
