Panasonic 2.2μF 50V dc Aluminium Electrolytic Capacitor, Through Hole 5 (Dia.) x 11mm +105°C 5mm 2mm [EEUHD1H2R2]; 744-2120
by Panasonic
0₫
Mã kho: 7442120
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 2.2 µF |
| Voltage | 50 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 5 (Dia.) x 11mm |
| Height | 11mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 5mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 2mm |
| Lifetime | 1000h |
| Series | HD RADIAL |
| Leakage Current | <=0.01 CV or 3 μA @ 2 min |
| Tolerance | ±20% |
| Ripple Current | 18mA |
