Panasonic 33μF 100V dc Aluminium Electrolytic Capacitor, Surface Mount 10 (Dia.) x 10.2mm +105°C 10mm 4.6mm [EEEFK2A330P]; 747-9119
by Panasonic
0₫
Mã kho: 7479119
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 33 µF |
| Voltage | 100 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 10 (Dia.) x 10.2mm |
| Height | 10.2mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 2000h |
| Lead Pitch | 4.6mm |
| Series | FK SMD |
| Polarised | Polar |
| Equivalent Series Resistance | 700mΩ |
| Leakage Current | 33 μA |
| Ripple Current | 200mA |
| Tolerance | ±20% |
