Panasonic 1000μF 10V dc Aluminium Electrolytic Capacitor, Surface Mount 10 (Dia.) x 10.2mm +105°C 10mm [EEEFK1A102AP]; 919-0679
by Panasonic
0₫
Mã kho: 9190679
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1000 µF |
| Voltage | 10 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 10 (Dia.) x 10.2mm |
| Height | 10.2mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 2000h |
| Series | FK SMD |
| Equivalent Series Resistance | 80mΩ |
| Tolerance | ±20% |
| Ripple Current | 850mA |
| Polarised | Polar |
| Leakage Current | 3 μA |
