Panasonic 180μF 20V dc Aluminium Polymer Capacitor, Through Hole 8 x 7mm +105°C 8mm 3.5mm [20SEPF180M]; 795-5553
by Panasonic
0₫
Mã kho: 7955553
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 180 µF |
| Voltage | 20 V dc |
| Mounting Type | Through Hole |
| Technology | Polymer |
| Dimensions | 8 x 7mm |
| Height | 7mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 8mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 3.5mm |
| Lifetime | 5000h |
| Series | OS-CON |
| Tolerance | ±20% |
| Equivalent Series Resistance | 25mΩ |
| Ripple Current | 3.2A |
| Leakage Current | 720 μA |
