Nippon Chemi-Con 470μF 35V dc Aluminium Electrolytic Capacitor, Through Hole 13 (Dia.) x 14.5mm +85°C 13mm 5mm [ESRG350ELL471MK13S]; 144-3985
0₫
Mã kho: 1443985
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 470 µF |
Voltage | 35 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 13 (Dia.) x 14.5mm |
Height | 14.5mm |
Minimum Operating Temperature | -40°C |
Diameter | 13mm |
Maximum Operating Temperature | +85°C |
Lead Pitch | 5mm |
Lifetime | 2000h |
Series | SRG |
Leakage Current | 3 μA |
Dissipation Factor | 0.0014 |
Ripple Current | 585mArms |
Tolerance | ±20% |
Polarised | Polar |
