Nippon Chemi-Con 470μF 35V dc Aluminium Electrolytic Capacitor, Through Hole 13 (Dia.) x 14.5mm +85°C 13mm 5mm [ESRG350ELL471MK13S]; 144-3824
0₫
Mã kho: 1443824
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 470 µF |
| Voltage | 35 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 13 (Dia.) x 14.5mm |
| Height | 14.5mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 13mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 2000h |
| Lead Pitch | 5mm |
| Series | SRG |
| Tolerance | ±20% |
| Leakage Current | 3 μA |
| Polarised | Polar |
| Dissipation Factor | 0.0014 |
| Ripple Current | 585mArms |
