Nippon Chemi-Con 3300μF 50V dc Aluminium Electrolytic Capacitor, Through Hole 18.5 (Dia.) x 37mm +85°C 18.5mm 7.5mm [ESMQ500ELL332MMP1S]; 146-8442
0₫
Mã kho: 1468442
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 3300 µF |
| Voltage | 50 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 18.5 (Dia.) x 37mm |
| Height | 37mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 18.5mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 7.5mm |
| Lifetime | 2000h |
| Series | SMQ |
| Dissipation Factor | 0.0016 |
| Ripple Current | 2500mArms |
| Tolerance | ±20% |
| Leakage Current | 4 μA |
| Polarised | Polar |
