Nippon Chemi-Con 1000μF 16V dc Aluminium Electrolytic Capacitor, Through Hole 10.5 (Dia.) x 14mm +85°C 10.5mm 5mm [ESMQ160ELL102MJC5S]; 146-8494
0₫
Mã kho: 1468494
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1000 µF |
| Voltage | 16 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 10.5 (Dia.) x 14mm |
| Height | 14mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 10.5mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 5mm |
| Lifetime | 2000h |
| Series | SMQ |
| Dissipation Factor | 0.002 |
| Tolerance | ±20% |
| Leakage Current | 4 μA |
| Polarised | Polar |
| Ripple Current | 700mArms |
